MFC AUTOMATIC LOADER

PRODUCT DESCRIPTION

This unit is used for loading of PCBs

FEATURES

  • Sturdy and stable design

  • User friendly ‘soft touch’ LED membrane control panel

  • Pneumatic clamps provided for magazine alignment

  • Pneumatic pusher’s pressure regulated

  • High throughput with short magazine change-over time

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.                Size         Machine Dimension (mm)L x W x H        Fixed Point to Front Dimension (X)       Weight(Approximately)

MFC0100LM             M                     1700 x 790 x 1330 mm                                         377 mm                                               145 kg

MFC0100LL               L                      2480 x 940 x 1330 mm                                         388 mm                                               220 kg

mfc atomatic loader

MFC AUTOMATIC UNLOADER

PRODUCT DESCRIPTION

This unit is used for unloading of PCBs

FEATURES

  • Includes pusher conveyor

  • Adjustable pusher position

  • Pneumatic pusher’s pressure regulated

  • Sturdy and stable design

  • User friendly ‘soft touch’ LED membrane control panel

  • Pneumatic clamps provided for magazine alignment

  • High throughput with short magazine change-over time

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.            Size              Machine Dimension (mm)L x W x H         Fixed Point to Front Dimension (X)     Weight(Approximately)

MFC0100UM         M                           2400 x 790 x 1330 mm                                           377 mm                                         180 kg

MFC0100UL           L                            3380 x 940 x 1330 mm                                           388 mm                                         280 kg

mfc automatic unloader

MFC BARE BOARD LOADER (WITH PASS THROUGH MODE)

PRODUCT DESCRIPTION

This unit is used for loading of bare PCBs to the production line

FEATURES

  • Enclosed design ensures highest level of safety

  • User friendly ‘soft touch’ LED membrane control panel

  • Adjustable suction cup positions provide better grips of PCBs

  • Smooth and parallel width adjustment

  • Small machine footprint

  • SMEMA compatible

CONFIGURATION

Model No.            Size        Machine Dimension (mm)L x W x H               Fixed Point to Front Dimension (X)     Weight(Approximately)

MFC0200PM         M                       500 x 720 x 1380 mm                                              234 mm                                               110 kg

MFC0200PL           L                        653 x 840 x 1380 mm                                              234 mm                                               140 kg

mfc bare board

MFC LINKING CONVEYOR

PRODUCT DESCRIPTION

This unit is used to link between SMD machines or board handling units.

FEATURES

  • Modular design

  • Stability enhanced by ‘robust design’

  • Ergonomically designed arm rest

  • Smooth and parallel width adjustment

  • Multi-zone concept available upon request

  • Different lengths available upon request

  • SMEMA compatible

  • Patented (SG Patent No: 91261)

TECHNICAL SPECIFICATIONS

Model No.               Size              Machine Dimension (mm)L x W x H        Fixed Point to FrontDimension (X)    Weight(Approximately)

MFC0401-M-500      M                           500 x 475 x 985 mm                                           142 mm                                           30 kg

MFC0401-L-500        L                            500 x 635 x 985 mm                                           142 mm                                           35 kg
MFC0401-M-1000    M                           1000 x 475 x 985 mm                                         142 mm                                           50 kg
MFC0401-L-1000      L                            1000 x 635 x 985 mm                                         142 mm                                           55 kg

mfc linking

MFC INSPECTION CONVEYOR (500&1000mm)

PRODUCT DESCRIPTION

This unit is used as a visual inspection station for operators between SMT machines or board handling units.

FEATURES

  • Modular design

  • Stability enhanced by ‘robust design’

  • Ergonomically designed arm rest

  • Smooth and parallel width adjustment

  • PCB inspection mode and bypass mode provided

  • Multi-zone concept available upon request

  • Different lengths available upon request

  • Variable speed control

  • SMEMA compatible

  • Patented (SG Patent No: 91261)

TECHNICAL SPECIFICATIONS

Model No.                    Size        Machine Dimension (mm)L x W x H     Fixed Point to Front Dimension (X)       Weight(Approximately)

MFC0501-M-500          M                        500 x 475 x 985 mm                                     142 mm                                                 30 kg

MFC0501-L-500            L                         500 x 635 x 985 mm                                     142 mm                                                 35 kg

MFC0501-M-1000        M                        1000 x 475 x 985 mm                                   142 mm                                                 50 kg

MFC0501-L-1000          L                         1000 x 635 x 985 mm                                   142 mm                                                 55 kg

mfc inspection

PRODUCT DESCRIPTION

This unit is used for removing dust, particles, glass fiber & etc on bare PCBs surface.

FEATURES

  • User friendly touch screen panel

  • Effective and user friendly cleaning solution

  • Single side cleaning

  • Static elimination and dust removal (vacuum)

  • Minimum maintenance of cleaning system

  • Smooth and parallel width adjustment (leadscrew)

  • Small machine footprint

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM0401-C-M        M                           500 x 620 x 1135 mm                                         186 mm                                           120 kg

NTM0401-C-L          L                            500 x 777 x 1135 mm                                         186 mm                                           130 kg

MFC WORKSTATION

mfc workstation

SINGLE MAGAZINE LOADER

PRODUCT DESCRIPTION

This unit is used for loading of PCBs to the production line.

FEATURES

  • User friendly ‘soft touch’ LED membrane control panel

  • Pneumatic clamps provided for magazine alignment

  • Pneumatic pusher’s pressure regulated

  • Adjustable pusher position

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM0700LM            M                           1230 x 1170 x 1330                                          380 mm                                              130 kg

NTM0700LL              L                            1515 x 1455 x 1330                                          380 mm                                              180 kg

single magazine loader

SINGLE MAGAZINE UNLOADER

PRODUCT DESCRIPTION

This unit is used for unloading of PCBs from the production line

FEATURES

  • User friendly ‘soft touch’ LED membrane control panel

  • Pneumatic clamps provided for magazine alignment

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM0700UM           M                        500 x 1170 x 1330 mm                                      380 mm                                                110 kg

NTM0700UL             L                         653 x 1455 x 1330 mm                                      380 mm                                                180 kg

single magazine unloader

AUTOMATIC LOADER/UNLOADER

PRODUCT DESCRIPTION

This unit is used for loading or unloading of PCBs.

FEATURES

  • Sturdy and stable design

  • User friendly ‘soft touch’ LED membrane control panel

  • Pneumatic clamps provided for magazine alignment

  • Pneumatic pusher’s pressure regulated

  • High throughput with short magazine change-over time

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM0100LM            M                            1870 x 750 x 1330                                            380 mm                                              180 kg

(Loader)
NTM0100LL              L                             2545 x 970 x 1330                                            395 mm                                               250 kg

(Loader)
NTM0100UM           M                            1870 x 750 x 1330                                            380 mm                                               180 kg

(Unloader)
NTM0100UL             L                             2545 x 970 x 1330                                            395 mm                                               250 kg

automatic loader/unloader

BARE BOARD LOADER (WITH PASS THROUGH MODE)

PRODUCT DESCRIPTION

This unit is used for loading of bare PCBs to the production line

FEATURES

  • Surrounded with covers to provide highest level of safety

  • Top safety cover can be opened for easy access to hardware during maintenance

  • User friendly ‘soft touch’ LED membrane control panel

  • Adjustable suction positions provide better grips of PCBs

  • Smooth and parallel width adjustment

  • Small machine footprint

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM0200-M             M                        500 x 730 x 1330 mm                                          234 mm                                               110 kg

NTM0200-L               L                         653 x 870 x 1330 mm                                          234 mm                                               140 kg

NTM0200PM            M                        500 x 730 x 1330 mm                                          234 mm                                               110 kg

(Pass through)
NTM0200PL              L                         653 x 870 x 1330 mm                                          234 mm                                               140 kg
(Pass through)

bare board loader

LINKING CONVEYOR (500 & 1000mm)

PRODUCT DESCRIPTION

This unit is used to link between SMD machines or board handling units

FEATURES

  • Modular design

  • Stability enhanced by ‘robust design’

  • Laser carved stainless steel side guides for superior quality and durability

  • Ergonomically designed arm rest

  • Smooth and parallel width adjustment

  • Multi-zone concept available upon request

  • Different lengths available upon request

  • SMEMA compatible

  • Patented (SG Patent No.: 91261)

TECHNICAL SPECIFICATIONS

Model No.                  Size        Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM0401-M-500       M                        500 x 570 x 985 mm                                           168 mm                                             45 kg

NTM0401-L-500         L                         500 x 727 x 985 mm                                           168 mm                                             50 kg

NTM0401-M-1000     M                        1000 x 570 x 985 mm                                         168 mm                                            60 kg

NTM0401-L-1000       L                         1000 x 727 x 985 mm                                         168 mm                                            70 kg

linking conveyor

INSPECTION CONVEYOR (500&1000mm)

PRODUCT DESCRIPTION

This unit is used as a visual inspection station between SMD machines

FEATURES

  • User friendly ‘soft touch’ LED membrane control panel

  • Modular design

  • Stability enhanced by ‘robust design’

  • Laser carved stainless steel side guides for superior quality and durability

  • Ergonomically designed arm rest

  • Smooth and parallel width adjustment

  • Multi-zone concept available upon request

  • Different lengths available upon request

  • Variable speed control

  • SMEMA compatible

  • Patented (SG Patent No.: 91261)

TECHNICAL SPECIFICATIONS

Model No.                      Size         Machine Dimension (mm)L x W x H     Fixed Point to Front Dimension (X)    Weight(Approximately)

NTM0501-M-500-1       M                         500 x 570 x 985 mm                                          168 mm                                          45 kg

NTM0501-L-500-1         L                          500 x 727 x 985 mm                                          168 mm                                          50 kg

NTM0501-M-1000-1     M                         1000 x 570 x 985 mm                                        168 mm                                          70 kg

NTM0501-L-1000-1       L                          1000 x 727 x 985 mm                                        168 mm                                          80 kg

inspection conveyor

PCB REJECT CONVEYOR

PRODUCT DESCRIPTION

Faulty boards can be lifted up for visual inspection without interrupting the PCBs flow

FEATURES

  • User friendly ‘soft touch’ LED membrane control panel

  • Includes ‘reject’, ‘inspect’ and ‘pass through‘ modes

  • Modular design

  • Stability enhanced by ‘robust design’

  • Ergonomically designed arm rest

  • Smooth and parallel width adjustment

  • Different lengths available upon request

  • Variable speed control

  • SMEMA compatible

  • Patented (SG Patent No.: 91261)

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM2500-M            M                         1000 x 667 x 980 mm                                          186 mm                                               80 kg

NTM2500-L              L                          1000 x 824 x 980 mm                                          186 mm                                               90 kg

pcb reject conveyor

WORKSTATION (1000mm)

PRODUCT DESCRIPTION

This unit is used to link between SMD machines or board handling units. It also allows manual assembly work to be carried out

FEATURES

  • User friendly ‘soft touch’ LED membrane control panel

  • Modular design

  • Stability enhanced by ‘robust design’

  • Laser carved stainless steel side guides for superior quality and durability

  • PCB inspection mode provided

  • Smooth and parallel width adjustment

  • Different lengths available upon request

  • Multi-zone concept available upon request

  • Equipped with lighting features, single layer part tray and adjustable foot rest

  • Variable speed control

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM1800-M            M                     1000 x 887 x 2190 mm                                       438 mm                                                 110 kg

NTM1800-L              L                      1000 x 1044 x 2190 mm                                     438 mm                                                 120 kg

workstation

PCB INVERTOR

PRODUCT DESCRIPTION

This unit is used to invert PCBs (180°) for “double-sided” process.

FEATURES

  • Equipped with built-in torque limiter to ensure highest level of safety

  • ‘Top safety cover’ can be opened for easy access to hardware during maintenance

  • User friendly ‘soft touch’ LED membrane control panel

  • Smooth and precise inverting motion

  • Subsequent inversions continue from the last unloading position (short cycle time)

  • Small machine footprint

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM0300-M             M                         500 x 730 x 1330 mm                                         234 mm                                                110 kg

NTM0300-L               L                          653 x 870 x 1330 mm                                         234 mm                                                120 kg

pcb invertor

IN-LINE PCB CLEANING MACHINE

PRODUCT DESCRIPTION

This unit is used for removing dust, particles, glass fiber & etc on bare PCBs surface

FEATURES

  • User friendly touch screen panel

  • Preset PCB counter and warning alarm will sound as reminder to change adhesive rolls

  • Double side cleaning (selectable)

  • Static elimination (double sided)

  • Easy access to adhesive rolls

  • Internal conveyor system to buffer board before cleaning

  • Smooth and parallel width adjustment (leadscrew)

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM5000-M            M                         653 x 800 x 1330 mm                                       220 mm                                               180 kg

NTM5000-L              L                          750 x 1050 x 1330 mm                                     220 mm                                               200 kg

inline pcb

VACUUM CONVEYOR

PRODUCT DESCRIPTION

This unit is used for removing dust, particles, glass fiber & etc on bare PCBs surface.

FEATURES

  • User friendly touch screen panel

  • Effective and user friendly cleaning solution

  • Single side cleaning

  • Static elimination and dust removal (vacuum)

  • Minimum maintenance of cleaning system

  • Smooth and parallel width adjustment (leadscrew)

  • Small machine footprint

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM0401-C-M        M                           500 x 620 x 1135 mm                                         186 mm                                           120 kg

NTM0401-C-L          L                            500 x 777 x 1135 mm                                         186 mm                                           130 kg

vacuum conveyor

MULTIFUNCTION BUFFER STOCKER

PRODUCT DESCRIPTION

This unit is used as a buffer between SMD machines or testers

FEATURES

  • User friendly ‘soft touch’ LED membrane control panel

  • First In First Out (FIFO), Last In First Out (LIFO), loader, unloader, reject stock and pass through operating modes

  • Fast, smooth and precise indexing (frequency inverter controller)

  • Pneumatic clamps provided for magazine alignment

  • Pneumatic pusher’s pressure regulated

  • Threshold system provided

  • Additional magazines buffering capacity available upon request

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM0600-M             M                      1260 x 1165 x 1330 mm                                        380 mm                                               200 kg

NTM0600-L               L                       1560 x 1455 x 1330 mm                                        380 mm                                               250 kg

Multifunction buffer

MULTIFUNCTION VERTICAL BUFFER

PRODUCT DESCRIPTION

This unit is used as a buffer between SMD machines

FEATURES

  • User friendly ‘soft touch’ LED membrane control panel

  • First In First Out (FIFO), Last In First Out (LIFO) and pass through operating modes

  • Flexible repositioning of ‘fingers’ (support bars) to accommodate jagged edge PCBs

  • Durable rollers as conveying medium (no replacement of belts needed)

  • Fast, smooth and precise indexing (frequency inverter controller)

  • Threshold system provided

  • Smooth and parallel width adjustment (leadscrew)

  • Small machine footprint

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM1400-M            M                        500 x 980 x 1700 mm                                          425 mm                                              210 kg

NTM1400-L              L                        653 x 1080 x 1700 mm                                         425 mm                                              240 kg

multifunction vertical buffer

DESTACKER

PRODUCT DESCRIPTION

This unit is used for loading of bare PCBs to the production line.

FEATURES

  • User friendly ‘soft touch’ LED membrane control panel

  • Uninterrupted loading

  • Pass through mode provided

  • Smooth and parallel width adjustment (leadscrew)

  • Small machine footprint

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM1200-M             M                          500 x 905 x 1330 mm                                      234 mm                                                150 kg

NTM1200-L               L                           500 x 905 x 1330 mm                                      234 mm                                                150 kg

destacker

PUSHUP STACKER

PRODUCT DESCRIPTION

This unit is used for restacking of PCBs from the production line.

FEATURES

  • User friendly ‘soft touch’ LED membrane control panel

  • Pass through mode provided

  • Smooth and parallel width adjustment (leadscrew)

  • Small machine footprint

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)       Weight(Approximately)

NTM2100-M            M                          500 x 905 x 1330 mm                                       234 mm                                              120 kg

NTM2100-L              L                           500 x 905 x 1330 mm                                       234 mm                                              140 kg

pushupstacker

TELESCOPIC GATE CONVEYOR (NORMALLY OPENED)

PRODUCT DESCRIPTION

This unit is used when a passage way is required in a production line (fully automatic)

FEATURES

  • User friendly ‘soft touch’ LED membrane control panel

  • Passage way ‘Normally Opened’ (850 mm)

  • Swift and smooth retraction/extension of conveyor (frequency inverter controller)

  • Safety sensor installed to enhance safety

  • Smooth and parallel width adjustment (leadscrew)

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM1700-M            M                        1500 x 775 x 1130 mm                                        234 mm                                              225 kg

NTM1700-L              L                         1500 x 905 x 1130 mm                                        234 mm                                              250 kg

telescopic gate conveyor

TELESCOPIC GATE CONVEYOR (NORMALLY CLOSED)

PRODUCT DESCRIPTION

This unit is used when a passage way is required in a production line (fully automatic)

FEATURES

  • User friendly ‘soft touch’ LED membrane control panel

  • Passage way ‘Normally Closed’ (745 mm)

  • Swift and smooth retraction/extension of conveyor (frequency inverter controller)

  • Additional built-in buffer zone

  • Safety sensor installed to enhance safety

  • Smooth and parallel width adjustment (leadscrew)

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM3600-M             M                        1500 x 780 x 1330 mm                                       292 mm                                               230 kg

NTM3600-L               L                         1500 x 930 x 1330 mm                                       292 mm                                               250 kg

telescopic

MANUAL LIFT GATE CONVEYOR

PRODUCT DESCRIPTION

This unit is used when a passage way is required in a production line. This unit is used when a passage way is required in a production line

FEATURES

  • 600 mm passage way or specify

  • Cylinder assisted lifting motion

  • Pneumatic locking device installed to enhance safety

  • Smooth and parallel width adjustment (leadscrew)

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM1500-M            M                       1000 x 790 x 1110 mm                                       194 mm                                                90 kg

NTM1500-L              L                        1000 x 920 x 1110 mm                                       194 mm                                              100 kg

manual conveyor.jpg
manual lift gate conveyor

TRAVERSER/SHUTTLE CONVEYOR

PRODUCT DESCRIPTION

This unit is used to redirect flow of PCBs into different channels in a production line

FEATURES

  • Surrounded with covers to provide highest level of safety

  • User friendly ‘soft touch’ LED membrane control panel

  • Swift, smooth and precise operations (frequency inverter controller)

  • PCB traffic flows can be customised

  • Smooth and parallel width adjustment

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.         Size    Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)              Weight(Approximately)

NTM0900-M       M                500 x W x 1100 mm                                            234 mm                               Depends on traversing distance

NTM0900-L         L                 653 x W x 1100 mm                                            234 mm                               Depends on traversing distance

traverser/shutte conveyor

TURN CONVEYOR/DIVERTER

PRODUCT DESCRIPTION

This unit is used to redirect PCBs in a production line

FEATURES

  • Equipped with built-in torque limiter to ensure highest level of safety

  • ‘Top safety cover’ can be opened for easy access to hardware during maintenance

  • User friendly ‘soft touch’ LED membrane control panel

  • Smooth and precise rotation

  • Transfer gap between conveyors is minimised

  • PCB traffic flows can be customised

  • Smooth and parallel width adjustment (leadscrew)

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.               Size           Machine Dimension (mm)L x W x H      Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM1100LM            M                        795 x 795 x 1100 mm                                          272 mm                                             160 kg

NTM1100LL              L                         875 x 875 x 1100 mm                                          234 mm                                             170 kg

NTM1100IM             M                        795 x 795 x 1100 mm                                          272 mm                                             160 kg

NTM1100IL               L                         875 x 875 x 1100 mm                                          234 mm                                             170 kg

NTM1100TM            M                        795 x 795 x 1100 mm                                          272 mm                                             160 kg

NTM1100TL              L                         875 x 875 x 1100 mm                                          234 mm                                             170 kg

NTM1100XM            M                        795 x 795 x 1100 mm                                          272 mm                                             160 kg

NTM1100XL              L                         875 x 875 x 1100 mm                                          234 mm                                             170 kg

Turn conveyor

INFEED CONVEYOR

PRODUCT DESCRIPTION

This unit is used for transferring of PCBs/pallets into the soldering machine.

FEATURES

  • Robust design

  • Two belt segments

  • Adjustable inclined angle (4° – 7°) or specify

  • Variable speed control to synchronise with wave soldering machine

  • PLC controlled (optional)

  • SMEMA compatible

TECHNICAL SPECIFICATIONS

Model No.          Size        Machine Dimension (mm)L x W x H              Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM2300IM        M       1000 x 535 x H1, H2 (specify upon order)                               50 mm                                               60 kg

NTM2300IL         L         1000 x 690 x H1, H2 (specify upon order)                               50 mm                                               70 kg

infeed conveyor

OUTFEED CONVEYOR

PRODUCT DESCRIPTION

This unit is used for transferring of PCBs/pallets from the soldering machine

FEATURES

  • Robust design

  • Sliding regulator provided

  • PLC controlled (optional)

  • Cooling fans (optional)

TECHNICAL SPECIFICATIONS

Model No.               Size         Machine Dimension (mm)L x W x H        Fixed Point to Front Dimension (X)        Weight(Approximately)

NTM2300-M            M        2500 x 535 x H1, H2 (specify upon order)                         50 mm                                               180 kg

NTM2300-L              L         2500 x 690 x H1, H2 (specify upon order)                         50 mm                                               200 kg

outfeed conveyor
bottom of page
